Heatit WiFi6 Thermostat

Name: Heatit WiFi6 Thermostat
Brand: Heatit
Price: 99.00 EUR
Availability: InStock

€99,00

Sale Sold out

Taxes included. Shipping calculated at checkout.

The Heatit WiFi6 Thermostat is a cutting-edge electronic thermostat designed for highly efficient control of both electrical underfloor heating and water-based heating systems. Featuring a user-friendly interface with an easy-to-read LCD display and capacitive buttons, it offers intuitive local operation. Its robust connectivity is based on Wi-Fi ( $2.4 GHz$ ) and Bluetooth Low Energy ( $BLE$ ), allowing for seamless configuration and control via the dedicated MyHeatit App. Built with a sturdy metal frame, this thermostat is engineered for secure installation in standard European junction boxes and is compatible with most System 55 frames, offering a modern and durable solution for your home's climate control.

Functionalities: Intelligent Energy and Comfort Management

The Heatit WiFi6 is packed with smart features to optimize your heating experience and reduce energy consumption:

Dual Connectivity & Control: Control your climate via the MyHeatit App over Wi-Fi, using the physical buttons on the thermostat, or for installation and local configuration via $BLE$ .
Active Power Metering: Gain real-time insight into your energy usage with the active power metering feature, helping you monitor and manage your electricity consumption for the heating system.
ZeroX™ Technology: This advanced technology extends the lifespan of the thermostat's internal relay by ensuring the switch-on and switch-off occurs precisely at zero voltage ( $0V$ ).
Multiple Sensor Modes: Utilize the built-in room temperature sensor, or connect optional wired external room and floor sensors for flexible and precise temperature measurement across various installation types.
Flexible Operating Modes: Choose from three distinct modes: Heat, Cool, and Eco, allowing the thermostat to be a central part of your home's climate strategy year-round.
Smart Scheduling and Profiles: Create custom weekly schedules and utilize predefined profiles such as Home, Away, Night, and Holiday within the app to automate temperature adjustments and maximize energy savings effortlessly.
Open Window Detection: Automatically cuts off heating when a rapid drop in temperature is detected, preventing wasted energy when a window is accidentally left open.
Regulation Methods: Supports both Hysteresis (temperature-based on/off switching) and PWM (Pulse Width Modulation) control for optimal temperature regulation.
Smart Home Readiness: Features an Open API for local gateway integration and is designed to support integration with popular voice assistants like Amazon Alexa and Google Home (support pending).

Technical Specifications

Feature	Specification
Protocol	$Wi-Fi (802.11 b/g/n) 2.4 GHz / Bluetooth Low Energy (BLE)$
Rated Voltage	$230 VAC 50 Hz$
Max Load (Resistive)	$3600 W$
Max Current (Resistive)	$16 A$ (Contactor recommended for loads above $13 A$ )
Own Power Usage	$\leq 2 W$
Temperature Range	$5^{\circ} C to 4 0^{\circ} C$
Hysteresis	$0. 3^{\circ} C to 3. 0^{\circ} C$ (Default $0. 5^{\circ} C$ )
Switch Type	One-pole switch
IP Code	$IP 21$
Ambient Temperature Range	$5^{\circ} C to 4 0^{\circ} C$
Compatible NTC-Sensors	$6.8, 10, 12, 15, 22, 33, 47, 100 k Ω @ 2 5^{\circ} C$ ( $Default 10 k Ω$ )
Power Regulator	Timed cycle $0 - 30 minutes$
Max. Connection Dimension	$2.5 mm^{2}$
Mounting	European Junction Box / $System 55 frames$
Certifications	$CE, Nemko, RoHS, Reach$
